ENR General Machining Co.

March 2016, Vol. 243, No. 3

The Model E2460 Tapping Machine from ENR General Machining Co. (ENR) provides a tapping size range of 24-60 inches with a Boring Bar Travel of 72, 120 and 140 inches. The machine has 6-inch 900# RTJ mounting flange as standard and is also available with a 600# RTJ front flange. The machine is hydraulically powered via a diesel hydraulic power unit. The ENR EQB-E2460 tapping machines is capable of operating up to 2,200 psig, allowing safe operations on lines up to full ANSI 900 operating pressures. The machine is operated via a hydraulic motor that provides speed-control features for cutter rotation. A separate hydraulic motor provides power extension and retraction of the boring bar. www.ENRHotTap.com
